AER "Dual Mix 2" Pocket Tool Two Channel Line/Mic Preamp with Effects

The AER Dual Mix 2 is a professional audio preamp, designed and manufactured to the highest pro audio technical specifications, capable of shaping, maximizing and delivering the tonal character of your instrument. The dual mix is a high-quality "two-channel" preamplifier for instrument/line or microphone signals. The unit offers simple, efficient features just like a small mixing console.

FEATURES:

• Two input stages for mic, instrument and line signal with switchable 24V phantom power
• Separate active two-band EQ networks for each input
• 4-preset multi-effects unit (2 x Reverb, 1 x Chorus, 1 x Delay)
• Stereo AUX-IN
• LINE-OUT and DI-OUT
• Stereo Headphone Pre-amp

SPECIFICATIONS:

• Inputs channel 1 and 2
  Switchable microphone or line input Combo socket, XLR and 1⁄4“ jack (6.35 mm)
• Equalizer
  Two band tone controls (high and low)
• Effects
  Four effects, 2 x Reverb, 1 x Chorus, 1 x Delay
• Power supply
  Voltage 24V = 0.5 A (Use only supplied mains adapter supplied)
• Features
  AUX-IN with level control, Headphones Pre-amp , HPF Filter, Mute via footswitch
• Dimensions
  Height: 65mm (2.56")
  Width: 105mm (4.13")
  Depth: 135mm (5.31")
  Weight: 480g (1.0 lbs)
